Triplett 310 - MEASURING OUTPUT VOLTS (dB); Output Voltage and dB Conversion

23
COM V-O-M
O
∞
SAFETY FIRST!
600Ω
1200V
DC
1200V
AC
AUDIO
AMPLIFIER
ACV
3
12
60
300
OHMS
ADJUST
CONTROL
POLARITY
REVERSING
SWITCH
(310-C ONLY)
MEASURING OUTPUT VOLTS (dB)
To read Output Voltage use the same procedure as shown on
page 17 for AC Voltage and convert readings to dB using the
chart on page 24.
