7
Installation
3. Optional: Using an HDMI 2.0 cable (such as Tripp Lite
P569-XXX-CERT or P568-XXX-2A-Series cables), connect the
HDMI source to the LOCAL port on the local transmitter unit.
4. Optional: Using your source’s PD power adapter, plug the
USB-C connector into the CHARGE IN port on the local
transmitter unit. The USB-C PD 3.0 port supports input up to
60W (20V 3A).
5. Using Cat6 cable, connect the RJ45 port on the local
transmitter unit to the RJ45 port on the remote receiver unit.
6. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT
or P568-XXX-2A-Series cables), connect the remote receiver
unit’s HDMI port to a monitor.
7. Turn on the power to your connected TVs/monitors. The LOCAL
(orange) LED will illuminate to indicate the local port has been
connected to a display.
8. Connect the external power supply to the local transmitter
unit and plug it into an available wall outlet or (optional) a
Tripp Lite Surge Protector, Power Distribution Unit (PDU) or
Uninterruptible Power Supply (UPS). The POWER (green) LED
on the local transmitter unit will illuminate to indicate the unit
is receiving power from the external power supply. The POWER
(green) LED on the remote receiver unit will illuminate to
indicate the unit is receiving power from the local transmitter
unit through PoC technology.
9. Turn on the power to the USB-C source. The OUTPUT (orange)
LED on the local transmitter unit will illuminate to indicate a
signal is being received from the source.
