14
Standard Extender/Splitter Installation
1. Make sure all equipment in the installation—such as TVs, Blu-ray
players and the transmitter—is powered OFF.
2. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT or
P568-XXX-2A Series cables), connect the HDMI source to the INPUT
port on the B127-002-H or B217-004-H units.
3. Optional for B127-004-H and B127-008H: Using an HDMI 2.0
cable (such as Tripp Lite P569-XXX-CERT or P568-XXX-2A Series
cables), connect an HDMI monitor to the LOCAL port on the
B127-004-H or B127-008H unit.
Note: Monitors with varying resolutions like 1080p or 4K 30 Hz can be
connected to the local HDMI port without affecting the 4K @ 60 Hz signal.
4. Using Cat6 cable, connect one of the RJ45 output ports on the local
transmitter unit to the RJ45 input port on a B127-100-H (up to
125 ft./38 m), B127-100-H-SR (up to 50 ft./15 m) or B127-200-H
(up to 125 ft./38 m) remote receiver unit.
5. Repeat step 5 for each additional remote unit being connected.
6. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT or
P568-XXX-2A Series cables). Connect the B127-100-H,
B127-100-H-SR or B127-200-H to a display.
7. Turn on the power to all your connected TVs or monitors. The LOCAL
(orange) LED will illuminate to indicate the port has been connected
to a display.
8. Connect the external power supply to the local transmitter unit and
plug it into an available wall outlet or (optional) a Tripp Lite Surge
Protector, Power Distribution Unit (PDU) or Uninterruptible Power
Supply (UPS). The POWER (green) LED will illuminate to indicate
the unit is receiving power from the external power supply. On the
B127-100-H and B127-200-H, the POWER (green) LED will
illuminate to indicate the unit is receiving power from the extender/
splitter. On the B127-100-H-SR, the (green) LED next to the RJ45
20-02-371-933918_Rev C.indd 1420-02-371-933918_Rev C.indd 14 3/6/2020 1:46:30 PM3/6/2020 1:46:30 PM
