18
Splitter Daisy-Chain Installation
(B127-004-H and B127-008H only)
11. Connect the external power supply to the local transmitter unit and
plug it into an available wall outlet or (optional) a Tripp Lite Surge
Protector, Power Distribution Unit (PDU) or Uninterruptible Power
Supply (UPS). The POWER (green) LED will illuminate to indicate the
unit is receiving power from the external power supply.
12. Repeat step 11 for each additional B127-004-H or B127-008H unit
in the daisy chain.
13. B127-000-H, B127-100-H-SR and B127-200-H: The green and
orange LEDs will illuminate, with the green LED indicating the unit
is receiving power from the extender/splitter, and the orange LED
indicating the unit is connected to a powered ON local unit via Cat6
cable.
14. Turn on the power to the HDMI source. The orange RJ45 LEDs will
illuminate on the B127-004-H or B127-008H to indicate the unit is
receiving a signal from the source. The screen should now display on
the connected monitors.
20-02-371-933918_Rev C.indd 1820-02-371-933918_Rev C.indd 18 3/6/2020 1:46:30 PM3/6/2020 1:46:30 PM
