6
Mounting Instructions
These 4-port presentation switches include hardware for mounting on a
wall, pole or 19-inch rack. The following images illustrate how the included
hardware can be attached for different installations.
Note: The models shown below are for illustrative purposes only. Your
product may vary by model number, size or port orientation. The mounting
options for all B320-Series switches are the same.
Wall-mount
19” Rack-mount Pole-mount
20-05-301-93-3C5E.indd 620-05-301-93-3C5E.indd 6 6/2/2020 11:36:45 AM6/2/2020 11:36:45 AM
