Assembly
6b
Install the Adapter Brackets
For Recessed-Back Screen or to Access A/V Inputs
Note: Choose appropriate screws, washers and spacers (if necessary) according to the type
of screen.
• Screw the adapter brackets onto the display.
Tighten all screws, but do not over-tighten.
M-C
M-D
M-E
M-D
M-E
M-D
M-E
M-F
M-G
M-G
M-G
M-H
M-H
M-C
M-F M-F
M-F
