Do not over-tighten screws.
4. Install the VESA Plate
Top of display
D5 Washer
Firmly attach the VESA plate to the display
using the provided hardware.
D5 Washer
M4X14
M5X14
M4X14
M5X14
or
TV
TV
TV
