6
3. Install the Wall Plate
(For clarit, outer cover is not shown.)
Anchor Bolt
Align the top hole of wall plate with the
fastened anchor bolt. Lower the wall plate
until the anchor bolt’s screw head is seated
in upper area of tear-drop mounting hole.
Install the other anchor bolt and level the
wall plate, then tighten all screws securely.
14-03-251-933335.indb 6 4/14/2014 1:59:33 PM
