5. Hang the display onto the Wall Plate
6. Adjustment
Push or pull from the top or bottom of display to obtain a desired angle.
Using an assistant or mechanical lifting equipment, hook the display
with attached VESA plate over the top of the mounted wall-plate.
Tighten the top screw on the VESA plate to secure the unit.
Maintenance
• Check that the bracket is secure and safe to use at regular intervals(at least every three months).
• Please visit www.tripplite.com/support if you have any questions.
Wall
Wall Wall
+10°
-15°
