Tripp Lite Power Supply - Specifications

18
Model: SU20K3/3INTXR5
Input
Input Voltage 220/380, 230/400, 240/415V AC,
3ø, 4 Wire (plus ground), wye
Input Frequency 50/60 Hz ± 3 Hz (auto-selectable)
Voltage Correction Range 156-280/270-485V AC
Input Current (Per Phase, On-Line) 30A/29A/28A
Inrush Current <300A
Power Factor (Full Load) >0.95
Efficiency (Full Load/On-Line) >92%
Circuit Breaker 50A (3p)
Input Bypass Circuit Breaker 50A (3p)
Output
VA 20000
Watts (Power Factor: 0.8) 16000
Waveform (On-Line) Sinewave
Waveform (On-Battery) Sinewave
Output Voltage (RMS) User-selectable 220/380, 230/400,
240/415V AC, 3ø, 4 Wire (plus ground), wye
Output Frequency 50/60 Hz (auto-selectable)
(± 0.1 Hz on battery)
Voltage Regulation ±2%
Max. Harmonic Distortion
(Non-Linear Full Load) <5%
Overload Capabilities
<
102% (continuous), 102%~125% (1 min.),
125%~150% (30 sec.),
>
150% (2 sec.)
Short Circuit Capability
>
167A
Crest Factor 3:1
Battery
Battery Type Sealed, Lead Acid, 240V DC, 9AH
Battery Pack Quantity Five Packs (20 12V DC Batteries per pack)
Protection Ten UL- or IEC- recognized 30A 600VDC
rated cartridge fuses (two per battery pack)
and fuse block (1 per battery pack)
Typical Backup Time (Half Load) 42 min. +
Typical Backup Time (Full Load) 17 min. +
Operation
On-Line Transfer Time
(Line to Battery, Battery to Line) 0 ms
Audible Noise (Full Load @ 1 meter) <65 dBA
Indicators
Includes an LCD Display and LEDs (AC Line In, Bypass Line In, AC to DC,
DC to AC, AC Output, Battery Back-Up, Bypass).
Communications
Includes an RS-232 DB9 female connector, an AS-400 DB9 female
connector, a dry contact DB9 female connector and an accessory slot.
Connections
Input Terminal Block 100A
Output Terminal Block 100A
Physical Specifications
Unit Dimensions (H x W x D) 48.5 x 19.3 x 36 in. (123.2 x 49 x 91.4 cm)
Unit Weight 935 lb. (424 kg)
Shipping Dimensions (H x W x D) 61.5 x 31 x 44.5 (156.2 x 78.7 x 113 cm)
Shipping Weight 1152 lb. (523 kg)
Model: SU20K3/3INT
Input
Input Voltage 220/380, 230/400, 240/415V AC,
3ø, 4 Wire (plus ground), wye
Input Frequency 50/60 Hz ± 3 Hz (auto-selectable)
Voltage Correction Range 156-280/270-485V AC
Input Current (Per Phase, On-Line) 30A/29A/28A
Inrush Current <300A
Power Factor (Full Load) >0.95
Efficiency (Full Load/On-Line) >92%
Circuit Breaker 50A (3p)
Input Bypass Circuit Breaker 50A (3p)
Output
VA 20000
Watts (Power Factor: 0.8) 16000
Waveform (On-Line) Sinewave
Waveform (On-Battery) Sinewave
Output Voltage (RMS) User-selectable 220/380, 230/400,
240/415V AC, 3ø, 4 Wire (plus ground), wye
Output Frequency 50/60 Hz (auto-selectable)
(± 0.1 Hz on battery)
Voltage Regulation ±2%
Max. Harmonic Distortion
(Non-Linear Full Load) <5%
Overload Capabilities
<
102% (continuous), 102%~125% (1 min.),
125%~150% (30 sec.),
>
150% (2 sec.)
Short Circuit Capability
>
167A
Crest Factor 3:1
Battery
Battery Type Sealed, Lead Acid, 240V DC, 9AH
Battery Pack Quantity Two Packs (20 12V DC Batteries per pack)
Protection Four UL- or IEC- recognized 30A 600VDC
rated cartridge fuses (two per battery pack)
and fuse block (1 per battery pack)
Typical Backup Time (Half Load) 17 min. +
Typical Backup Time (Full Load) 5 min. +
Operation
On-Line Transfer Time
(Line to Battery, Battery to Line) 0 ms
Audible Noise (Full Load @ 1 meter) <65 dBA
Indicators
Includes an LCD Display and LEDs (AC Line In, Bypass Line In, AC to DC,
DC to AC, AC Output, Battery Back-Up, Bypass).
Communications
Includes an RS-232 DB9 female connector, an AS-400 DB9 female
connector, a dry contact DB9 female connector and an accessory slot.
Connections
Input Terminal Block 100A
Output Terminal Block 100A
Physical Specifications
Unit Dimensions (H x W x D) 35.3 x 19.3 x 36 in. (89.7 x 49 x 91.4 cm)
Unit Weight 520 lb. (236 kg)
Shipping Dimensions (H x W x D) 43 x 28 x 44.5 in. (109.2 x 71.1 x 113 cm)
Shipping Weight 609 lb. (276 kg)
Specifications
+ Backup times are expandable with additional Battery Packs, sold separately. The policy of Tripp Lite is one of continuous improvement. Specifications are subject to change without notice.
