aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.
Keep the appliance and its cord out of reach of children aged less than 8 years. Cleaning and user
maintenance shall not be made by children unless older than 8 and supervised.
The appliance is not intended to be operated by means of an external timer or a separate remote-control
system.
Any use of the appliance other than described in this user manual is regarded as misuse and may cause
injury or damage to the appliance and void the warranty.
Main parts (see image A)
1
Air inlet
2
 Airlter
3
Control panel
4
Power cord
5
Air outlet
6
Castor
7
Drainage hole
8
Hose connector (window
end)
9
Hot-air exhaust hose
q
Hose connector (Air
conditioner end)
w
Window seal + Velcro
e
Remote control
r
Batteries
Control panel (see image B)
t
 Poweron/o󰀨
y
Fan speed
u
Temperature up
i
Temperature down
o
Mode button
p
 Timeron/o󰀨
a
 Swingon/o󰀨
s
Sleep mode
d
Cooling indicator
f
Dehumidifying indicator
g
Fan indicator
h
WiFi indicator
j
High/Medium/Low fan speed
indicator
k
Water full indicator
Remote control (see image C)
l
 Poweron/o󰀨
z
 Timeron/o󰀨
x
Mode
c
°C / F° selector
v
Temperature up
b
Temperature down
n
LED Display
m
Auto swing
Q
Fan speed
W
Sleep mode
E
Receiving signal
R
Cooling function
T
Dehumidifying function
Y
Fan function
U
Auto swing
I
Current timer
O
 Timeron/o󰀨
P
Sleep mode
A
Fan speed
S
Temperature display
Technical specications
Appliance name Air Conditioner
Model PD-3821
Cooling capacity 3800W
Heating capacity N/A
Refrigerant R290/226g
Permissible excessive operating
pressure
Discharge 2.6MPa
Suction 1.0MPa
Maximum allowable pressure Discharge 3.2MPa
Suction 1.2MPa
Rated voltage 220 – 240 V~
Rated frequency 50Hz
