PRODUCT FAMILIARISATION
1. Front Handle
2. Power Indicator
3. On/Off Trigger Switch
4. Trigger Safety Lock
5. Main Handle
6. Fixed Rear Base
7. Fence Attachment Point (x 4)
8. Drive Belt Cover
9. Front Handle Lock Lever
10. Fence Attachment Point (x 4)
11. Moveable Front Base
12. Depth Adjustment Knob
13. Front Handle Set Screw
14. Blade Barrel
15. Reversible Blades
16. Clamping Screw (x 5)
17. Blade Spanner
18. Dust/Chip Extraction Port
19. Dust Extraction Adaptor
20. Combined Parallel and Bevel Fence Guide
21. Fence Attachment Knob (x 2)
Know your product
1
12
2 3 4 5
67
811
13
14 15 16
1718192021
9
10
366649_Z1MANPRO2.indd 3 07/07/2014 10:24
