ELECTRONIC SCORER OPERATION
Unscrew screw using a screwdriver and open the battery box. Insert 3 AA batteries ( not included) in the order of
polarity as shown on the inside cover. Then close the cover using a screwdriver. Turn the power ON using the
ON/OFF switch. (if the game will not be used for a long period of the time, we recommend that the batteries
should be removed).
To fold the basketball game into the storage position, remove the Lock Pins (#33) from the
playing position on the Mounting Tubes (#6) & (#8). Lift the Front Horizontal Ramp Support
Tube (#11) until the game is in the storage position as shown in FIG. 12
Control Wire
Visitor
On/Off switch
Insert the Lock Pins (#33)
back into the Mounting
Tubes (#6) & (#8), locking
the basketball game into
the storage position.
33
FIGURE 12
12
For Customer Service Call 1-888-996-2729
© 2017 Escalade S por t s
All Rights Reserved
This device complies with the part 15 of the FCC rules. Operation is subject to the following two
conditions :
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Please study each diagram closely and read all assembly notes to insure correct assembly
