Perform the following operations:
• Seat - Removal
• Battery - Removal
• Fuel Tank - Removal
• Plenum - Removal (All Markets Except US) or Plenum - Removal (US Markets
Only)
NOTICE
The fuel rail and injectors are removed from the cylinder head together.
1. Disconnect the electrical connector from the six fuel injectors.
2. Remove the two fixings securing the fuel rail and fuel rail covers to the cylinder head.
Collect the spacers between the fuel rail and cylinder head and the cover.
1. Injector connector (2 of 6 shown)
2. Fixings
3. Cover
4. Spacers
3. Gently ease the fuel rail and injectors upwards to release them from the cylinder
head.
