5. Route the preload adjuster hose and secure to its retaining clip as noted for removal.
6. Fit the rear suspension preload adjuster to the battery box and tighten the fixings to
15 Nm.
1. Fixings
2. Preload adjuster
3. Retaining band
4. Rear suspension unit
7. With the weight of the motorcycle on its wheels, fit a new flanged lock nut. Hold the
nut and tighten the bolt to 48 Nm.
8. Hold the flanged lock nut and tighten the upper fixing bolt to 48 Nm.
9. Connect the engine ECM connectors (see Engine Electronic Control Module
(Engine ECM) - Installation).
Perform the following operations:
• Keyless ECM - Installation
• Right hand Side Panels - Installation
• Fuel Tank - Installation
• Battery - Installation
• Seat - Installation
