Parts Identification
Parts Identification (continued)
1. C l u t c h l e v e r
2. Passing button
3. Headlight dimmer switch
4. Speedometer
5. Trip computer display
6. Tachometer
7. Warning lights
8. Front brake fluid reservoir
9. Engine stop switch
10.Front brake lever
11. H o r n b u t t o n
12.Turn signal switch
13.Ignition switch
14.Immobilzer
15.Starter button
cgfs
432 5 6 7 8 9 10
13 1511 12
1
14
