General Information
Left Handlebar Switches
1. Headlight dimmer switch
2. Turn signal switch
3. Horn button
4. Pass button
Headlight Dimmer Switch
High or low beam can be selected with the
headlight dimmer switch. To select high
beam, push the switch forward. To select low
beam, push the switch rearwards. When the
high beam is turned on, the high beam
indicator light will illuminate.
Note:
• A lighting on/off switch is not
fitted to this model. The headlight,
tail light and license plate light all
function automatically when the
ignition is turned to the ON
position.
Turn Signal Switch
When the turn signal switch is pushed to the
left or right and released, the corresponding
turn signals will flash on and off. To turn off
the turn signals, push and release the switch.
Horn Button
When the horn button is pushed, with the
ignition switch turned to the ON position, the
horn will sound.
Pass Button
When the pass button is pressed the
headlight main beam will be switched on. It
will remain on as long as the button is held in
and will turn off as soon as the button is
released.
