Triumph Speed Twin 900 User Manual

GENERAL INFORMATION
43
Average Fuel Consumption
Scrambler 900 and Speed Twin 900 Only
1
2
1. Average symbol
2. Average fuel consumption
All Other Models
21
1. Average symbol
2. Average fuel consumption
This is an indication of the average
fuel consumption. After being reset the
display will show dashes until 0.1 miles/
km has been covered.
After refueling, the average
consumption information will be
updated only while riding the
motorcycle. Depending on the riding
style, updating could take up to five
minutes.
Trip Meter
Warning
Do not attempt to switch between
the odometer and trip meter display
modes or reset the trip meter with the
motorcycle in motion as this may lead
to loss of motorcycle control and an
accident.
1
1. Trip meter display (Trip 1 selected)
There are two trip meters. Either trip
meter shows the distance that the
motorcycle has traveled since the meter
on display was last reset to zero.

Triumph Speed Twin 900 Specifications

General

Displacement	900 cc
Bore x Stroke	84.6 mm x 80 mm
Compression Ratio	11.0:1
Max Power	65 PS / 64.1 bhp (47.8 kW) @ 7, 500 rpm
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle frame
Front Tire	100/90-18
Rear Tire	150/70 R17
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Exhaust	Brushed 2 into 2 exhaust system with twin silencers
Front Suspension	41mm telescopic forks, 120mm travel
Rear Suspension	Twin shocks, adjustable preload, 120mm rear wheel travel
Front Brakes	Single 310 mm disc, Brembo 4 piston caliper, ABS
Rear Brakes	Single 255mm disc, Nissin 2 piston floating caliper, ABS
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12 litres
Dry Weight	198 kg
Width Handlebars	760 mm
Height Without Mirror	1110 mm
Wheelbase	1450 mm
