ELECTRICAL SYSTEM
43
KEY TO FIG. 65
1. Generator
2. Control Box
3. Ignition Warning Light
4. Battery
5. Ignition/Starter Switch
5a. Ignition/Starter Switch-
Radio Supply Position
6. Starter Solenoid
7. Starter Motor
8. Ignition Coil
9. Ignition Distributor
10. Master Light Switch
11. Instrument Illumination
12. Lights Selector Switch
13. Main Beam Warning Light
14. Main Beam
15. Dip Beam
16. Fuse Assembly
17. Horn Relay
18. Horn Push
19. Horn
20. Tail Lamp
21. Plate Illumination Lamp
22. Front Parking Lamp
23. Reverse Lamp Switch
24. Reverse Lamp
25. Voltage Stabilizer
26. Fuel Indicator
27. Fuel Tank Unit
28. Temperature Indicator
29. Temperature Transmitter
30. Heater Switch (Optional)
31. Heater Motor (Optional)
32. Flasher Unit
33. Direction Indicator Switch
34. L.H. Direction Indicator Lamb
35. R.H. Direction Indicator Lamp
36. Direction Indicator Warning Light
37. Stop Lamp Switch
38. Stop Lamp
39. Windscreen Wiper Motor
40. Windscreen Wiper Switch
41. Oil Pressure Warning Light
42. Oil Pressure Switch
OVERDRIVE (OPTIONAL)
43. Overdrive Relay
44. Overdrive Column Switch
45. Overdrive Gearbox Switch
46. Overdrive Solenoid
a. From Ignition/Starter Switch-
Connector 2
b. From Ignition/Starter Switch-
Connector 1
CABLE COLOUR CODE
N Brown LG Light Green
U Blue W White
R Red Y Yellow
P Purple B Black
G Green
