Triumph Sprint GT 1050 User Manual

43
General Information
To remove each pannier:
Note:
• The same procedure can be
followed to remove and mount the
left hand or the right hand
panniers.
1. L o c k
2. Carrying handle
To unlock and remove the pannier from the
pannier mountings, turn the key to the
RELEASE position and lift the carrying handle
to its fully raised position. Lift the pannier free
from the pannier mountings.
Pannier Operation
1. Key slot (shown in the LOCK
position)
2. Lock position symbol
3. Unlock position symbol
4. Release position symbol
To unlock and open the pannier, insert the
key and turn it to the UNLOCK position,
then press down on the latch plate. The lid
can then be opened.
1. L o c k
2. Latch plate
1
cgds
2
2
3
4
1
1
cgds
2

Triumph Sprint GT 1050 Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Engine Capacity	1050 cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Max Torque	108 Nm @ 6, 300 rpm
Exhaust	Stainless steel 3 into 1 exhaust system
Frame	Aluminium beam perimeter
Front Suspension	43 mm upside down forks with adjustable preload
Rear Suspension	Monoshock with adjustable preload and rebound damping
Front Brakes	Twin 320mm floating discs, Nissin 4-piston calipers
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper
Seat Height	815 mm
Fuel Tank Capacity	20 litres
Max Power	130 PS / 128 bhp (96 kW) @ 9200 rpm
