Triumph Tiger 1200 GT Pro 2023 User Manual

MAINTENANCE AND ADJUSTMENT
144
To protect the cooling system from
corrosion, the use of corrosion inhibitor
chemicals in the coolant is essential.
If coolant containing a corrosion
inhibitor is not used, the cooling system
will accumulate rust and scale in the
water jacket and radiator. This will block
the coolant passages, and considerably
reduce the efficiency of the cooling
system.
Coolants of different types must not be
mixed. Mixing coolants of different
types will reduce the performance of
the coolant and reduce its life. When
replacing coolant, it is recommended to
thoroughly flush the cooling system
with clean water.
Coolant Level Inspection
The expansion tank can be viewed from
the left hand side of the motorcycle. The
coolant level within the expansion tank
can be inspected without removing any
covers.
NOTICE
If the coolant level is being checked
because the coolant has overheated,
also check the level in the radiator and
top up if necessary.
In an emergency, distilled water can
be added to the cooling system.
However, the coolant must then be
drained and replenished with D2053
OAT coolant as soon as possible.
2
1
3
1. Expansion tank cover
2. Maximum mark
3. Minimum mark
To inspect the coolant level:
▼ Position the motorcycle on level
ground and in an upright position.
▼ Make sure that the engine is cold (at
room or ambient temperature).
▼ Check the coolant level in the
expansion tank. The coolant level
must be between the maximum and
minimum marks.
▼ If the coolant is below the minimum
level, the coolant level must be
adjusted.

Triumph Tiger 1200 GT Pro 2023 Specifications

General

Displacement	1160 cc
Bore x Stroke	90.0 mm x 60.7 mm
Compression Ratio	13.2:1
Transmission	6-speed
Front Tire	120/70R19
Cruise Control	Yes
Heated Grips	Yes
Cornering ABS	Yes
Hill Hold Control	Yes
Keyless Ignition	Yes
Engine Type	Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
Fuel System	Multipoint sequential electronic fuel injection
Front Brakes	Dual 320mm discs, Brembo Stylema 4-piston calipers
Rear Brakes	Single 282mm disc, Brembo 2-piston caliper
Front Wheel	19 x 3.0in
Rear Wheel	18 x 4.25in
Seat Height	850mm (adjustable)
Fuel Capacity	20 L (5.3 US gal)
Weight (Wet)	245 kg
Instruments	7-inch TFT display
Lighting	LED
Riding Modes	Rain, Road, Sport, Off-Road, Rider-configurable
Traction Control	Yes
Torque	130 Nm (96 lbft) @ 7, 000 rpm
