17
CV PAR Description Range Value Notes
34 062 Function mapping, F0, LR 0 – 255 2
35 063 Function mapping, AUX 1 0 – 255 4
36 064 Function mapping, AUX 2 0 – 255 8
37 065 Function mapping, AUX 3 0 – 255 0
38 066 Function mapping, switching range 0 – 255 16
39 067 Function mapping, AUX 4 0 – 255 0
40 – 50
068 –
078
Function mapping, F6 – F16
52 081 Dimming, lighting 0 – 255 255
54 083 Dimming, AUX 1 0 – 255 255
55 084 Dimming, AUX 2 0 – 255 255
64 097 Starting voltage, analog 0 – 255 0
65 025 Kick start 0 – 255 96
112 034 Measurement Reference 1 – 31 24
113 051 Response curve 0 – 7 5
0 = linear,
7 = max. dipping
114 053 Pulse width in milliseconds 0 – 255 8
115 052 Damping action 0 – 7 3
116 056 Response behavior 0 – 11 6
119 017 Maximum speed, analog 2 – 255 255
120 016 Acceleration delay from FS0 to FS1 0 – 255 1
121 021 Stopping section 0 / 1 0 One or two-part
122 022 Speed in a 2-part braking section 0 – 127 32
123 023 Braking time in stopping sections 0 – 255 5
