Trix 66841 - CV and Parameter List

16
CV and Parameter List
CV PAR Description Range Value Notes
1 — Short address (7 bits) 0 – 127 3
2 014 Minimum speed 0 – 255 1
3 011 Acceleration delay 0 – 255 5
4 012 Braking delay 0 – 255 5
5 013 Maximum speed 0 – 127 92
8 101 Reset CV 8 = 8; PAR 101 = 101
9 054 PWM frequency 0 / 1 0 0 = 32 kHz; 1 = 16 kHz
10 010 Max. measurement period in milliseconds 0 – 63 12
13 046 F1 – F8 in analog operation 0 – 255 0
14 047 F9 – F14 and lighting in analog operation 0 – 255 3
17 Long address (14 bits), upper byte 192 – 231 195
18 Long address (14 bits), lower byte 0 – 255 242
19 M.U. address 0 – 127 0
21 048 F1 – F8 with M.U. 0 – 255 0
22 049 F9 – F14 and lighting with M.U. 0 – 255 0
27 DCC braking operation 0 – 63 18
29 045
Bit 0: Polarity reversal, direction
Bit 1: Number of speed levels 14 or 28/128 *
Bit 2: DCC operation with braking section
Bit 5: Address length 7 bits / 14 bits
6
30 030 Error memory 0
1 = Excess temperature
2 = too high current consumption
33 061 Function mapping F0, LV 0 – 255 1
