Trix 66841 - Motor Control Settings Variants Preset

18
CV PAR Description Range Value Notes
130 096 Safety settings 0 – 255 142
132 099 Minimum speed, analog 0 – 255 128
133 100 Minimum voltage, analog 0 – 255 0
134 114 Dimming, lighting, analog 0 – 255 128
135 115 Dimming, AUX 1, analog 0 – 255 128
136 116 Dimming, AUX 2, analog 0 – 255 128
137 117 Temperature sensor 0 – 85
138 118 Shutoff temperature 0 – 85 80
139 119 Current monitoring 0 – 255 100 Value * 10 = safety value in milliamps
001 Long address, 10th / 1st placeholders 0 – 99 0
002 Long address, 1,000th / 100th placeholders 0 – 99 0
003 Short address 0 – 112 1
007 Mode of Operation for the Function Address 0 – 3 0
008 M.U. address, 10th / 1st placeholders 0 – 99 1
009 M.U. address, 1,000th / 100th placeholders 0 – 99 10
160 050 Motor control preset (control variants) 0 – 3 2
Motor Control settings variants preset
Variants,
CV 160 (PAR 050)
Max. Measurement Time
CV 10 (PAR 010)
Kickstart
CV 65 (PAR 25)
Damping Action
CV 115 (PAR 52)
Response Behavior
CV 116 (PAR 56)
0 6 32 1 4
1 8 64 2 5
2 12 96 3 6
3 24 128 4 8
