GB/IE/NI 10
P Technical specifications
Built-in rechargeable battery:
3.7 V
, 10,000 mAh,
37Wh (Lithium polymer)
USB type C input and output
voltage / current (PD):
5 V
, 3 A /
9 V
, 2 A/
12 V
,1.5 A
USB type A output voltage /
current:
5 V
, 3 A /
9 V
, 2 A/
12 V
,1.5 A
Wireless charging power: 10 W max
Wireless charging distance: ≤ 5 mm
Charging efficiency: up to 86%
Frequency band: 136.40 - 147.60 kHz
Transmitted maximum radio
frequency power (H-field):
-17 dBuA/m at 10m
distance
Maximum total output power: 15 W*
Maximal total output current: 3 A*
Minimal output current: approx. 100 mA
Operating temperature: 5 – 35 °C
Storage temperature: 0 – 45 °C
Humidity (no condensation): 10 –70 %
Dimensions: approx.
145 x 74 x 18 mm
Weight: approx. 260 g
*If all outputs are used at the same time, the sum of the output
current must not exceed 3 A (5 V
3 A, 15 W).
