Trotec BE17 User Manual

4 EN
voltage detector BE17
Residual risks
Warning of electrical voltage
Risk of death due to electric shock!
An electric shock can result in severe personal injury or
death! The device may only be used by qualified
electricians in accordance with all safety instructions
listed here.
Warning of electrical voltage
Electric shock due to insufficient insulation! Check the
device for damages and proper functioning before each
use.
If you detect damages, do not use the device any
longer.
Do not use the device when wither the device or your
hands are damp or wet!
Do not use the device when the battery compartment
or the housing is open.
Warning of electrical voltage
Electric shock due to contact with live parts! Do not
touch any live parts. Secure neighbouring live parts by
covering them or by switching them off.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution
Keep a sufficient distance from heat sources.
Note
Test the device for proper functioning at a known
voltage source before each measurement.
Note
To prevent damages to the device, do not expose it to
extreme temperatures, extreme humidity or moisture.
Note
Do not use abrasive cleaners or solvents to clean the
device.
Information about the device
Device description
The bipolar voltage detector serves to indicate voltage ranges
between 12 and 400VDC or 12 and 400VAC. The voltage
amounts are displayed in 7sections on an LED display with their
polarity being indicated.
The device may be used in facilities of overvoltage category3
(CATIII= domestic installations).
The device further has a function for residual current device
(RCD) testing and tripping.
Device depiction
1
2
3
4
12
24
36
50
120
230
400
TEST
2
3
No. Designation
1 Test probeL1(+)
2 LED display
3 TEST button
4 Test probeL2(–)

Trotec BE17 Specifications

General

Brand	Trotec
Model	BE17
Category	Test Equipment
Language	English
