6 EN
voltage detector BE17
2. Hold both test probesL1(1) and L2(4) to the measuring
points to be tested.
ð The LED display(2) is illuminated according to the
existing voltage.
ð The LED display(2) indicates the type of voltage and the
respective polarity. If both indicators+ and– are
illuminated simultaneously, there is an AC voltage.
Testing the residual current protection
Using the TEST button(3), the function of the residual current
device can be tested (RCDtest).
If contact is being made with the phase and the protective
conductor while the Test button(3) is simultaneously actuated,
residual current is simulated and the according residual current
device (RCD) trips. If the residual current device does not trip,
have the electric installation checked by a professional
electrician.
Maintenance and repair
Cleaning
Clean the device with a soft, damp and lint-free cloth. Make
sure that no moisture enters the housing. Do not use any
sprays, solvents, alcohol-based cleaning agents or abrasive
cleaners, but only clean water to moisten the cloth.
Repair
Do not modify the device or install any spare parts. For repairs
or device testing, contact the manufacturer.
Disposal
The icon with the crossed-out waste bin on waste
electrical or electronic equipment stipulates that this equipment
must not be disposed of with the household waste at the end of
its life. You will find collection points for free return of waste
electrical and electronic equipment in your vicinity. The
addresses can be obtained from your municipality or local
administration. For further return options provided by us please
refer to our website www.trotec24.com.
The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.
