Trotec BN30 - Transport and Storage; Transport; Storage; Technical Data

4 EN
socket thermostat BN30
Display
8 9 10
11
1213
No. Designation
8 Cooling mode indication
9 Heating mode indication
10 SET indication
11 °C/°F indication
12 OFF indication
13 Target value or current room temperature display
Technical data
Parameter Value
Model BN30
Weight 220g
Dimensions (heightx
widthx depth)
140 x 60x 75mm
Temperature setting range 5°C to 49°C (41°F bis 85°F) in
increments of 0.5
Operating conditions -10 to 70°C
Measuring interval 10s
Power supply 230V AC/ 50Hz
Load (max.) 16A / 3680VA - ohmic load
2A / 460VA - inductive load
Scope of delivery
• 1x Socket thermostat BN30
• 1 x Quick guide
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
For transporting the device use a suitable bag to protect it from
external influences.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• protected from dust and direct sunlight
• with a cover to protect it from invasive dust if necessary
• the storage temperature complies with the values specified
in the Technical data
