Trotec TDS 20 R User Manual

EN 11
electric heater TDS 20 R / TDS 30 R / TDS 50 R
Technical annex
Technical data
Parameter Value
Model TDS 20 R TDS 30 R TDS 50 R
Heating capacity
level1:
level2:
level3:
ventilation only
1500W
3000W
ventilation only
2500W
5000W
ventilation only
4500W
9000W
Air flow rate 411m
3
/h 580m
3
/h 844m
3
/h
Operating range -20°C to +45°C -20°C to +45°C -20°C to +45°C
Mains connection 1/N/PE~230V/ 50Hz 3/N/PE~400V/ 50Hz 3/PE~400V/ 50Hz
Max. power input 3000W 5000W 9000W
Nominal current
consumption
13.04 A 7.22 A 13 A
Fusing 16 A 16 A 16 A
Plug type CEE 7/7 CEE16A, 5-pin CEE16A, 5-pin
Cable length 1.37 m 1.20 m 1.20 m
Sound pressure level
(at a distance of 1m)
53dB(A) 56dB(A) 56dB(A)
Weight 3 kg 5 kg 6.5 kg
Dimensions (lengthx
widthx height) 210x 195x 270(mm) 275x 220x 330(mm) 315x 250x 370(mm)
Minimum distance to walls
and other objects
top(A):
rear(B):
sides(C):
front(D):
50cm
50cm
50cm
50cm
50cm
50cm
50cm
50cm
50cm
50cm
50cm
50cm

Trotec TDS 20 R Specifications

General

Brand	Trotec
Model	TDS 20 R
Category	Electric Heater
Language	English
