Trotec TIH300S User Manual

10 EN
infrared heating panel TIH 300 S / TIH 400 S / TIH 500 S / TIH700 S / TIH 900 S / TIH 1100 S
Technical annex
Technical data
Parameter Value
Model
TIH 300 S TIH 400 S TIH 500 S
Article number 1.410.003.008 1.410.003.010 1.410.003.012
Heating capacity 300 W ± 5 % 450 W ± 5 % 580 W ± 5 %
Mains connection 1/N/PE ~ 230V/ 50Hz 1/N/PE ~ 230V/ 50Hz 1/N/PE ~ 230V/ 50Hz
Nominal current 1.3 A 2.0 A 2.6 A
Connection type CEE 7/7 (SchuKo) CEE 7/7 (SchuKo) CEE 7/7 (SchuKo)
Cable length 1.9 m 1.9 m 1.9 m
Efficiency 98 % 98 % 98 %
Surface temperature 70-90 °C 70-90 °C 70-90 °C
Type of protection IP 54 IP 54 IP 54
Weight 2.5 kg 3.5 kg 5 kg
Dimensions
(width x height x depth)
605x 505x 22 (mm) 705x 605x 22 (mm) 905x 605x 22 (mm)
Minimum distances
top (A):
rear (B):
sides (C):
front (D):
50 cm
0 cm
10 cm
30 cm
50 cm
0 cm
10 cm
30 cm
50 cm
0 cm
10 cm
30 cm
Parameter Value
Model
TIH 700 S TIH 900 S TIH 1100 S
Article number 1.410.003.014 1.410.003.016 1.410.003.018
Heating capacity 700 W ± 5 % 900 W ± 5 % 1100 W ± 5 %
Mains connection 1/N/PE ~ 230V/ 50Hz 1/N/PE ~ 230V/ 50Hz 1/N/PE ~ 230V/ 50Hz
Nominal current 3.2 A 3.9 A 4.8 A
Connection type CEE 7/7 (SchuKo) CEE 7/7 (SchuKo) CEE 7/7 (SchuKo)
Cable length 1.9 m 1.9 m 1.9 m
Efficiency 98 % 98 % 98 %
Surface temperature 70-90 °C 70-90 °C 70-90 °C
Type of protection IP 54 IP 54 IP 54
Weight 6.5 kg 8 kg 9 kg
Dimensions
(width x height x depth)
1,205x 605x 22 (mm) 1,205x 755x 22 (mm) 1,205x 905x 25 (mm)
Minimum distances
top (A):
rear (B):
sides (C):
front (D):
50 cm
0 cm
10 cm
30 cm
50 cm
0 cm
10 cm
30 cm
50 cm
0 cm
10 cm
30 cm
