Trotec TTK54E - Technical Annex

16 EN
dehumidifier TTK 54 E / TTK 66 E
Technical annex
Technical data
Parameter Value
Model TTK54E TTK66E
Max. dehumidification performance 16 l/24h 24 l/24h
Dehumidification performance @ 30°C and 80%RH 14 l/24h 20 l/24h
Air flow rate 150 m
3
/h 168 m
3
/h
Ambient temperature 5°C to 32°C 5°C to 32°C
Operating range 35 % to 85 %RH 35 % to 85 %RH
Pressure suction side 1.0MPa 1.0MPa
Pressure outlet side 2.6MPa 2.6MPa
Max. permissible pressure 2.6MPa 2.6MPa
Power supply 220–240V/ 50Hz 220–240V/ 50Hz
Power consumption max. 0.43 kW 0.44 kW
Nominal current 2.2 A 2.3 A
Refrigerant R290 R290
Amount of refrigerant 75 g 75 g
GWP factor 3 3
CO
2
equivalent 0.00023t 0.000225t
Condensation tank capacity 3 l 3 l
Sound pressure level (atadistance of1m) 46 dB(A) 46 dB(A)
Dimensions (lengthx widthx height) 245x 350x 510 mm 245x 350x 510 mm
Minimum distance to walls and other objects
A: top:
B: rear:
C: side:
D: front:
40 cm
20 cm
20 cm
20 cm
40 cm
20 cm
20 cm
20 cm
Weight 15 kg 15 kg
