pedestal fan TVE 16 / TVE 18 S
Information about the device
Device description
The pedestal fans of the TVES series are suitable for indoor air
circulation.
The device TVE 16/ TVE 18 S comes with the following
features:
• 3 speed levels
• Height adjustability
• Inclination angle of the fan head vertically adjustable by up
to 30°
• On-demand 90°oscillation
Device depiction
1
2
3
4
5
6
No. Designation
1 Protective grid
2 Control panel
3 Foot
4 Stand
5 Motor
6 Oscillation pin
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
To make the device easier to transport, it is fitted with a carry
handle.
Before transporting the device, observe the following:
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Do not use the power cable to drag the device.
After transporting the device, proceed as follows:
• Set up the device in an upright position after transport.
Storage
Before storing the device, proceed as follows:
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
When the device is not being used, observe the following
storage conditions:
• Store the device in a dry location and protected from frost
and heat.
• If required, use a cover to protect the device from invasive
dust.
• Place no further devices or objects on top of the device to
prevent it from being damaged.

Trotec TVE 16 Specifications

General

AC input voltage	220 - 240 V
Power source type	AC
AC input frequency	50 Hz
Power consumption (typical)	50 W
Type	Household blade fan
Placement	Floor
Cord length	1.5 m
Noise level	52.5 dB
Fan diameter	400 mm
Product color	White
Auto oscillating	Yes
Number of speeds	3
Oscillation range	90 °
Height adjustment range	1100 - 1290 mm

Weight and Dimensions

Width	520 mm
Height	1290 mm
Weight	2414 g
