Trotec TVM 18 S User Manual

8 EN
floor fan TVM 18 S
2. Unscrew the connection screw(10) below the protective
grid(1).
10
3. To reinstall the protective grid after cleaning, screw in the
connection screw(10) and close the six fastening clamps
again.
Cleaning the fan blades
ü The device is switched off.
ü The power cable has been removed from the mains socket.
1. Remove the protective grid following the instructions
above.
2. Clean the fan blades with a soft, damp and lint-free cloth.
Ensure that no moisture enters the housing. Protect
electrical components from moisture. Do not use any
aggressive cleaning agents such as cleaning sprays,
solvents, alcohol-based or abrasive cleaners to dampen
the cloth.
• Other than that, the device does not require maintenance.
Technical annex
Technical data
Model: TVM 18 S
Fan stages: 3
Air velocity: 3.85 m/s
Input voltage: 220 - 240 V / 50 Hz
Power input: 100 W
Length of the power cable: 1.5 m
Storage and operating
conditions:
• dry and protected from
frost and heat
• in an upright position
• protected from direct
sunlight
Adjustable inclination angle: 110°
Adjustable in height: 107 - 135 cm
Sound pressure level (at 1m
distance, stage 2):
65 dB(A)
Fan blade diameter: 45 cm
Dimensions
(length x width x height):
450 x 540 x 1,350 (mm)
Weight: 8 kg
Minimum distance to walls and
other objects:
top (A):
rear (B):
sides (C):
front (D):
30 cm
30 cm
30 cm
30 cm
