15
Model 494
Ref.
No.
Part No. Part Description
1 11480 Stop Washer
2 681-0118 Inlet Guide Assembly
3 681-0144 Arm Bracket Assembly
4 710-0542 Hex Flange Bolt: 5/16-18 x 8.375”
5 710-0607 Hex Washer Screw: 5/16-18 x 0.5”
6 710-3256 Button-Head Screw 1/4-20 x 0.5”
7 712-0429 Lock Nut: 5/16-18
8 712-3027 Hex Flange Lock Nut: 1/4-20
9 714-0104 Internal Cotter Pin
10 715-0129 Spiral Pin
11 726-0106 Cap Nut
12 726-0135 Speed Cap Nut
13 728-0175 Pop Rivet
14 732-0546 Torsion Spring
15 732-0629 Hopper Door Spring
16 735-0127 Rubber Washer
17 735-0651 Hopper Flap
18 736-0119 Lock Washer
19 738-0137A Shdr. Scr: .340 x .285 x 1/4-20
20 738-0946 Shdr. Scr: .56 x .165 x 5/16-18
21 747-0531A Rel. Rod: 5/16” dia.
22 747-0747 Hopper Door Rod
23 747-1124 Flap Retaining Rod
24 747-1125 Flap Retaining Bail
25 781-0492A Hopper Pivot Door
26 781-0633 Chute Flap Strip
27 781-0698 Hopper Lock Bracket
28 781-0715 Shredder Plate
29 781-0752 Flap Mounting Bracket
30 781-0754 Upper Hopper
31 781-0755 Lower Hopper
32 738-0813 Shredder Axle
33 731-1899 Chipper Chute
37 710-0751 Hex Bolt 1/4-20 x .625
38 736-0173 Flat Washer .28 I.d. x .74 O.d.
39 712-3027 Flanged Lock Nut
40 749-1004 Chipper Chute Support
41 710-0106 Hex Scr. 1/4-20 x .625 (Gr. 2)
43 712-3010 Hex Nut 5/16-18 Thd. (Gr. 5)
44 736-0242 Bell Washer .345” I.d. x .88”
45 735-0249 Shredder Chute Flap
48 681-0068A Chipper Chute Assembly
49 726-0214 Push Cap 5/8” dia.
50 734-0255 Air Valve
51 750-0793 Chute Hinge Spacer
52 712-3027 Hex Ctr. Lock Nut 1/4-20 Thd.
53 714-0149B Internal Cotter Pin
55 720-0170 Hand Knob
56 710-0805 Hex Bolt 5/16-18 x 1.5”
57 781-0510B Shredder Frame
58 736-0366 Flat Washer 1.12 x .64 x .120
59 734-1797 Wheel Assembly
61 736-0170 Special Lock Washer
63 681-0117 Flail Housing Ass’y. (Inner)
65 710-0157 Hex Bolt 5/16-24 x .75” Lg.
67. 731-1617 Tamper Plug (If Equipped)
68 742-0544 Chipper Blade
69 712-0411 Hex Top Lock Nut 5/16-24
70 736-0119 Lock Washer 5/16” I.d.
71 681-0030 Impeller assembly
72 742-0571 Shredder Blade
73 781-0457 Shredder Screen
74 681-0094 Discharge Chute Assembly
75 781-0735 Retaining Clip
76 715-0166 Spring Roll Pin
78 710-1054 Flat Head Scr. 5/16-24 x .75”
79 710-3008 Hex Bolt 5/16-18 x .75”
80 681-0004A Flail Housing Ass’y. (Outer)
82 710-0825 Hex Bolt 1/4-20 x 3.75”
83 726-0211 U Nut 5/16-18
85 711-0835 Clevis Pin
87 719-0329 Flail Blade
88 711-0833B Clevis Pin
89 710-1254 Hex Patch Bolt 3/8-24 x 2.25”
90 736-0217 Lock Washer 3/8”
91 736-0247 Flat Washer .406” I.d. x 1.25”
92 732-0306 Compression Spring
93 736-0117 Flat Washer
94 714-0104 Internal Cotter Pin
95 711-1304 Axle Shaft
96 736-0160 Flat Washer
97 634-04009 Complete Wheel: Grey
98 726-0299 Push Cap
99 747-0982 Lock Rod
100 764-0501 Shredder Bag
