18 Section 7— Service
 Remove all dirt and clean the area around the transmission
cover. See Fig. 7-3.
Figure 7-3
Transmission
Housing
Transmission
Cover
Hex Screw
5. Remove the four hex screws (⁄
transmission cover to the drive shaft and remove the cover.
See Fig. 7-3
 Remove the left-side wheel. Tilt the left-side wheel shaft
into a drain pan and allow the gear oil to drain through the
top of the transmission.
7. Reinstall the wheel and reinstall the transmission cover.
8. Refill the transmission using Mobil 1®
Refill the engine with motor oil and replenish the fuel tank
with gasoline.
 Reinstall the belt cover.

Troy-Bilt Bronco CRT Specifications

General

Number of Forward Speeds	1
Number of Reverse Speeds	1
Tilling Width	18 in.
Tilling Depth	8 inches
Warranty	2 years limited
Starting System	Recoil start
