NOTE: Download a complete Parts Manual free of charge at www.troybilt.com or phone (800) 828-5500 to purchase a Parts Manual.
Be sure to have your model number and serial number ready. These can be found on the model plate located under the seat. Refer to
page 2 for more information regarding locating your model and serial numbers.
Component Part Number and Description
954-04060B Deck Belt (42” Mowing Deck)
918-04822A Deck Spindle
942-04308 Blade (42” Deck)
942-04308-X Extreme Blade (42” Deck)
925-1707D Battery
951-12179A Fuel Tank Cap
951-12426 Fuel Tank Cap (CA Models Only)
625-05002 Key Asm-Black Key W/Keychain
734-1731 Tire (Front) 15 x 6 x 6 Square Shoulder
734-1730 Tire (Rear) 20 x 8 x 8 Square Shoulder
746-04367 Throttle Control/Cable
631-04288 Discharge Chute Assembly
Replacement Parts
