Troy-Bilt CSV 204 User Manual

17
Model CSV 204
Ref
No.
Part Number Description
1. 781-0633 Chute Flap Strip
2. 735-0249 Chute Flap
3. 728- 0175 Pop Rivet
4. 731-1838A Discharge Chute
5. 964-04001 Bag
6. 631-0086 Nozzle Assembly
7. 731-1831 Nozzle Flap
8. 710-0969 Screw
9. 720-0426 Height Adjustment Knob
10. 732-0754 Spring Lever
11. 781-0702-0637 Index Bracket RH
12. 781-0703-0637 Index Bracket LH
13. 938-0913 Shoulder Screw
14. 736-3084 Flat Washer, .510 x 1.12 x.060
15. 912-0431 Hex Flange Lock Nut, 3/8-16
16. 631-0049 Door Assembly
17. 731-1574A Chipper Chute
18. 710-0751 Hex Cap Screw, 1/4-20 x.620
19. 736-0173 Flat Washer, .28 ID x.74 OD
20. 912-3027 Hex Lock Nut, 1/4-20
21. 781-0780-0637 Support Bracket
22. 681-0068A-0638 Chipper Chute Assembly
23. 912-3010 Hex Nut, 5/16-18
24. 736-0242 Bell Washer, .340ID x.872OD
25. 981-04091 Impeller Assembly: Complete
26. 719- 04308 Flail Blade
27. 712-0266A Jam Lock Nut, 3/8-16
28. 734-1984 Hub Cap
29. 738-04286 Shoulder Pin, .5 x 2.625
30. 93 6 - 0119 Lock Washer, 5/16
31. 710-1054 Cap Screw 5/16-24 x 1.0
32. 942-0544 Chipper Blade
33. 912 - 0 411 Hex Lock Nut 5/16-24
34. 736-0247 Flat Washer, .406 x 1/1/4
35. 936 -0217 Lock Washer, 3/8
36. 710 -1273 Hex Cap Screw, 3/8-24 x 2.75
Ref
No.
Part Number Description
37. 723-0438 Rubber Seal
38. 710-0604A Hex Washer Screw, 5/16-18
39. 912-0384 Hex Lock Nut, 1/2-13
40. 781-0627-0638 Chipper Blade Cover
41. 712-3004A Hex Flange Lock Nut 5/16-18
42. 681-0098-0638 Housing Assembly: Inner Flail
43. 781-0599-0637 Upper Shredder Blade
44. 710-0772 Hex Cap Screw, 5/16-18 x 2
45. 781-0653-0637 Flail Housing Blade
46. 710-3008 Hex Cap Screw, 5/16-18 x.75
47. 719-0326 Discharge Screen
48. 681-0060-0638 Housing Assembly: Outer Flail
49. 929-0241A Wire Harness
50. 710-0896 TT Screw, 1/4-14 x 0.625”
51. 726-0272 Clamp
52. 710-0382 Hex Cap Screw, 1/2-13 x 5.0
53. 712-0421 Knob, 5/16-18
54. 925-3166 Switch
55. 931-1613 Safety Switch Mounting Cover
56. 710 -1268 Hex Washer Screw
57. 925-1700 Switch Cover
58. 710 -1260A LD Screw, 5/16-18 x 0.75”
59. 912-3027 Hex Flanged Lock Nut, 1/4-20
60. 948-0188B Pawl, .345 ID -LH
748-0381 Pawl, .345 ID - RH
61. 710 -0157 Hex Cap Screw, 5/16-24 x.75
62. 936-3008 Flat Washer, .344 x.75 x.12
63. 747-0929A Belt Keeper
64. 629-0923 Adapter Harness Assembly
65. 736-0366 Flat Washer, 5/8 ID x 1.0 OD
66. 634-0244 Wheel Complete 10 x 4 x 4
67. 912-0456 Hex Nut, 1/4-20
68. 10622BP Plastic Spring Ratchet
69. 748- 0405 Wheel Ratchet 1.62 OD x.5 serr
70. 914-0104 Cotter Pin

Troy-Bilt CSV 204 Specifications

General

Brand	Troy-Bilt
Model	CSV 204
Category	Chippers/Shredders
Language	English
