12 SECTION 3— ASSEMBLY & SET-UP
Adjusting the Seat
To adjust the position of the seat, rotate the seat forward and locate
the clamp knobs on the front of the seat pan. Refer to Figure 3-2.
Rotate the clamp knobs to the left and remove them, slide the
seat forward or backward and re-insert the clamp knobs into
one of the four available positions on the seat pan and into the
seat, then tighten both securely. Make sure the seat is locked into
position before operating the tractor. See Figure 3-7.
Clamp
Knob
Seat
Adjustment
Positions
Figure 3-7
Fuel Fill-Up
Using a good grade of unleaded regular gasoline, fill the tank
(beside the engine on the left side of the mower). When the fuel
tank reaches one inch from the top of the tank, stop, DO NOT
OVERFILL. Space must be left for expansion.
