Page #3 background imageLoading...
Page #3 background image
3
Fig. 6
Fig. 7
A
A
C
B
D
A. Holding Slots A. Encoches de retenue A. Ranuras de sujeción
A. Outer Spool
B. Spring
C. Inner Reel
D. Eyelets
A. Bobine extérieure
B. Ressort
C. Enrouleur intérieur
D. Œillets
A. Bobina exterior
B. Resorte
C. Carrete interior
D. Ojetes
