TROY-BILT LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Printed In USA
Op e r a t O r ’s Ma n u a l
Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
Self Propelled Mower — Models TB210 & TB270 ES
Form No. 769-05334
(February 17, 2010)

Table of Contents

Questions and Answers

  • K
    Kevin MurilloAug 18, 2025
    What to do if Troy-Bilt TB270 ES Lawn Mower engine runs erratic?
    • R
      Rebecca VincentAug 18, 2025
      If your Troy-Bilt lawn mower engine runs erratically, it could be due to a loose spark plug boot; connect and tighten it. A blocked fuel line or stale fuel could also be the cause; clean the fuel line and fill the tank with clean, fresh gasoline. Another possibility is a plugged vent in the gas cap, so clear the vent. Water or dirt in the fuel system can also cause this issue; drain the fuel tank and refill with fresh fuel. If the unit is running with the choke applied, push the choke knob in. For a dirty air cleaner, refer to the engine manual.
  • J
    Joseph CarrollAug 21, 2025
    Why Troy-Bilt TB270 ES Lawn Mower engine overheats?
    • M
      Monica GriffinAug 21, 2025
      If your Troy-Bilt lawn mower engine overheats, it could be due to a low engine oil level; fill the crankcase with the proper oil. Another cause could be restricted airflow; clean the area around and on top of the engine.
  • H
    hannah09Aug 25, 2025
    What to do if Troy-Bilt TB270 ES will not self propel?
    • D
      Dr. Amy JordanAug 25, 2025
      If your Troy-Bilt lawn mower won't self-propel, check the belt for proper pulley installation and movement. Debris clogging the drive operation could also be the cause; stop the engine, disconnect the spark plug boot, and clean out any debris. Inspect the belt for damage or wear and replace it if necessary.
  • C
    Christopher WardAug 28, 2025
    Why Troy-Bilt TB270 ES will not mulch grass?
    • J
      Joseph SmithAug 28, 2025
      Your Troy-Bilt lawn mower might not mulch grass effectively if the grass is wet; do not mow when the grass is wet, wait until later to cut. If the grass is excessively high, mow once at a high cutting height, then mow again at the desired height or make a narrower cutting path. A dull blade can also cause this issue; sharpen or replace the blade.
  • E
    Emily HarrisSep 1, 2025
    How to fix uneven cut with Troy-Bilt TB270 ES?
    • G
      Gabriela CarsonSep 1, 2025
      To fix an uneven cut with your Troy-Bilt lawn mower, ensure the wheels are positioned correctly by placing the front and rear wheels in the same height position. Also, check if the blade is dull; sharpen or replace it if necessary.
  • K
    Kenneth BirdSep 4, 2025
    Why Troy-Bilt TB270 ES idles poorly?
    • J
      Jeremy DuffySep 4, 2025
      If your Troy-Bilt lawn mower idles poorly, it could be due to a spark plug that is fouled, faulty, or has a gap that is too wide; reset the gap to .030” or replace the spark plug. Alternatively, the air cleaner may be dirty; refer to the engine manual.
  • H
    Henry AllenSep 7, 2025
    What causes excessive vibration in Troy-Bilt TB270 ES?
    • K
      Katherine SchneiderSep 7, 2025
      Excessive vibration in your Troy-Bilt lawn mower can be caused by a cutting blade that is loose or unbalanced; tighten the blade and adapter and balance the blade. Another cause could be a bent cutting blade; consult an authorized service dealer.
  • J
    Joanne GardnerSep 12, 2025
    What to do if Troy-Bilt Lawn Mower occasionally skips at high speed?
    • K
      kelleyjamesSep 12, 2025
      If your Troy-Bilt lawn mower occasionally skips (hesitates) at high speed, the spark plug gap might be too close; adjust the gap to .030”.
  • W
    William AguilarNov 14, 2025
    Why Troy-Bilt TB270 ES Lawn Mower engine fails to start?
    • J
      Joseph KleinNov 14, 2025
      Your Troy-Bilt lawn mower engine might fail to start due to several reasons. It could be that the blade control is disengaged, so engage the blade control. Another reason might be a disconnected spark plug boot, so connect the wire to the spark boot. The fuel tank might be empty or contain stale fuel, so fill the tank with clean, fresh gasoline. If your mower has a primer, the engine might not be primed, so prime it as instructed in the Operation section. Other potential causes include a faulty spark plug (clean, adjust gap, or replace), a blocked fuel line (clean it), or a flooded engine (wait a few minutes to restart, but do not prime). Also, check if the fuel valve is closed (open it) or if the engine is not choked (choke it). For electric start models, a burnt fuse could be the issue (...

Summary

To The Owner

Customer Support

Contact information and resources for assistance with assembly, operation, or maintenance.

Important Safe Operation Practices

General Operation

General guidelines for safe and correct operation of the mower.

Slope Operation

Guidelines for safe mowing on slopes, including what to do and not to do.

Children

Safety precautions regarding children around the mower.

Service

Safe Handling Of Gasoline

Precautions for handling gasoline safely to prevent injury and fire.

Blade Care

Instructions for inspecting, removing, and servicing the cutting blade.

General Service

Do not modify engine

Warning against modifying the engine, especially the governor setting.

Replacing Battery (If Equipped)

Charging Battery (If Equipped)

Off-Season Storage

Assembly & Set-Up

Handle

Instructions for assembling the mower's handle.

Adjustments

Cutting Height

How to adjust the cutting height of the mower.

Set-Up

Instructions for filling gas and oil before initial operation.

Controls and Features

Blade Control

Explanation of the blade control lever and its function.

Drive Control

Description of the drive control for engaging the self-propel feature.

Cutting Height Adjustment Lever

Recoil Starter

Electric Start Ignition Switch (If Equipped)

Operation

Starting Engine

Step-by-step instructions for starting the engine safely.

Stopping Engine

How to safely stop the engine and blade.

Using Your Lawn Mower

General guidance on operating the mower, including safety warnings.

Using as Mulcher

Using Grass Catcher

Maintenance & Adjustments

Lubrication

Deck Care

Deck Wash (If Equipped)

Engine Care

Key engine maintenance tasks like air cleaner and spark plug care.

Troubleshooting

Engine Fails to start

Lists causes and remedies for the engine failing to start.

Engine runs erratic

Lists causes and remedies for erratic engine operation.

Engine overheats

Occasional skips (hesitates) at high speed

Idles poorly

Excessive Vibration

Lists causes and remedies for excessive vibration.

Mower will not mulch grass

Uneven cut

Mower will not self propel

Lists causes and remedies for the mower not self-propelling.

Troy-Bilt TB270 ES Specifications

General IconGeneral
Engine Type4-Cycle
Engine BrandBriggs & Stratton
Engine Displacement140 cc
Cutting Width21 inches
Deck MaterialSteel
Drive SystemSelf-Propelled
Mulch CapableYes
Side DischargeYes
Bagging CapableYes
Bag Capacity1.9 bushels
Wheel Size (Front)8 inches
Cutting Height1.25-3.75 inches
Drive TypeRear Wheel Drive
Wheel Size (Rear)11 inches
Cutting Height AdjustmentSingle-lever
