9
ASSEMBLING AND USING THE SHOULDER STRAP
(OPTIONAL)
Assembling the Shoulder Strap
1. Push the strap up through the center slot in the buckle (Fig. 7).
2. Bend the strap over and push it down through the lower slot in
the buckle (Fig. 7).
Using the Shoulder Strap
1. Put the shoulder strap over the operator’s head and onto the left
shoulder.
2. Start the unit. Refer to Starting and Stopping.
3. Snap the clip onto the shoulder strap / harness loop (Fig. 8).
4. Adjust the shoulder strap to fit the operator (Fig. 9). Pull the
buckle up to loosen the shoulder strap. Pull the strap down to
tighten the shoulder strap.
Fig. 7
Strap
Buckle
Clip
Fig. 8
Clip
Fig. 9
Strap
Buckle
Center
Slot
Lower Slot
Shoulder Strap
/ Harness Loop
