Brake Pedal
Forward Drive Pedal
Reverse Drive Pedal
Headlight
Parking Brake Lever
Fuel Level Indicator
Ignition Switch Module
Throttle/Choke Lever
Cup Holder
Oil Fill Cap
Fuel Fill Cap
Deck Lift Lever
PTO Lever
Figure 4-1
Lawn Tractor controls and features are illustrated in Figure 4-1 and described on the following pages.
WARNING! Read and follow all safety rules and instructions in this manual, including the entire Operation section,
before attempting to operate this machine. Failure to comply with all safety rules and instructions may result in personal
injury.
Controls & Features
4
15
