Troy-Bilt TB575es - Handle and Throttle Assembly Parts

REPLACEMENT PARTS - MODEL TB575es
4-CYCLE GAS TRIMMER
PPN 41CDT57C966
Issued 6/09
Item Part No. Description
1 753-04234 Throttle Housing Assembly (includes 2-4)
2 753-04119 Throttle Trigger
3 791-182690 Throttle Trigger Spring
4 791-182405 Switch
5 753-05266 Throttle Cable Assembly
6 753-04236 Upper Drive Shaft Housing Assembly
7 753-06039 Deluxe D-Handle Assembly (includes 8)
8 753-06040 Bolt
9 753-1190 Split Boom Coupler (includes 10-13)
10 791-182057 Screw
11 791-181617 Bolt
12 791-181981 Adjustment Knob (includes 13)
13 753-04386 Knob Retaining Nut
14 753-06139 Lower Drive Shaft Housing Assembly
15 753-05267 Lower Flexible Drive Shaft
16 753-05698 Anti-Rotation Screw
17 753-06124 Gear Box Assembly (includes 16)
18 753-06125 Shield Mounting Screws
19 753-06123 Shield Assembly (includes 20)
20 753-06126 Blade Assembly
21 769-06129 Cutting Head Assembly
* Items Not Shown
1
11
12
13
1
8
7
9
10
6
3
2
14
15
18
19
5
21
17
4
16
20
