PARTS LIST
REPLACEMENT PARTS - MODEL TBE515
4-CYCLE GAS EDGER
Item
Part No. Description
1 753-05206 Engine Cover Assembly (includes 2 & 3)
2 753-04595 Cover Screw
3 753-05377 Screw
4 753-05209 Rocker Cover
5 753-05210 Rocker Cover O-Ring
6 753-05228 Cylinder Assembly (includes 3, 5 & 9)
7 753-05229 Piston Ring Assembly
8 753-05230 Piston Assembly (includes 7)
9 753-05232 Cylinder O-Ring
10 791-182379 Breather Hose
11 753-05236 Oil Plug (includes 12)
12 791-182290 Oil Plug O-Ring
13 753-05237 Crankcase Cover
14 753-05238 Crankcase Cover O-ring
15 753-05503 Crankcase Assembly (includes 9, 10, 14 & 16)
16 753-05240 Flywheel Assembly
17 753-05241 Cam Bracket Assembly (includes 18)
18 753-05242 Cam Bracket Screw
19 753-05504 Lead Wires
20 753-05243 Module Assembly
21 753-05244 Muffler Gasket
22 753-05245 Muffler Assembly (includes 21 & 23)
23 753-05246 Muffler Screw
24 753-05255 Spark Plug
25 753-05247 Insulator Gasket
26 753-05248 Nut
27 753-05249 Insulator (includes 28)
28 753-05366 Carburetor Gasket
29 753-05251 Carburetor w/Primer
Item Part No. Description
30 753-04030 O-Ring
31 753-05507 Air Filter Mounting Screw
32 753-05505 Air Cleaner Cover Assembly
(includes 33, 34 & 37-39)
33 791-182097 Breather Tube
34 791-181000 Grommet Washer
35 791-182409 Washer
36 753-04993 Nut
37 753-182657 Air Filter Plate
38 753-05506 Air Filter
39 791-182659 Air Filter Cover
40 753-05256 Fuel Tank Assembly w/Fuel Lines (includes 41)
41 753-1229 Fuel Cap
42 753-05259 Fuel Tank Pads
43 753-05260 Push Nut
44 753-1202 Pressure Plate Screw
45 753-05074 Pressure Plate (includes 44)
46 753-05078 Spacer
47 753-05435 Starter Assembly (includes 48)
48 753-05509 Rope
49 753-04286 Recoil Spring
50 791-181079 Handle
51 791-611061 Rope Guide
52 753-05262 Starter Housing Assembly (includes 3 & 43-51)
53 791-182396 Washer
54 753-04595 Screw
* 753-05297 Spark Arrestor Assembly
* 753-05511 Shortblock Assembly
(includes 3-12, 14, 15, 17 & 24)
