Bridge Mode
Bridge mode combines both the left and right channels to a single channel mono signal output. Bridge mode is
stable down to a minimum load of 8Ω.
Power output bridged:
275W @ 8Ω
IR Connection, Control and Learning
Learning
This amplifier can learn the following commands (off, on, mute, volume down & volume up) from a TVs IR remote.
The IR receiver can receive a signal to about 15-20 feet away.
TREBLE
Remote
4
8Ω LOAD
8Ω
SIGNAL
RECEIVING ZONE
IR RECEIVER
TOP VIEW
SIGNAL
RECEIVING ZONE
IR RECEIVER
FRONT VIEW
