Getting started.
Before AIS CTRX GRAPHENE is installed, you should check that you have all the
equipment you need for the installation and that nothing is missing from your
delivery. The AIS CTRX GRAPHENE comes in two versions the GRAPHENE and the
GRAPHENE+ version. The plus version also contains a built in antenna splitter
making it possible to use the same VHF antenna for both the AIS and the VHF radio.
AIS CTRX GRAPHENE comes with the following parts:
1
AIS CTRX GRAPHENE Class B Transponder
P/N 0012-001-000
1
Data and DC cable (1 m)
P/N 0012-770-000
1
USB cable 1 m
P/N 0012-980-000
1
BNC to UHF adapter
P/N 0012-989-000
1
CD incl. manual, set up software and AIS information
P/N 0012-972-000
AIS CTRX GRAPHENE + comes with the following parts:
1
AIS CTRX GRAPHENE Class B Transponder
P/N 0012-002-000
1
Data and DC cable (1 m)
P/N 0012-770-000
1
USB cable 1 m
P/N 0012-980-000
1
BNC to UHF adapter
P/N 0012-989-000
1
Cable (2 m) AIS to VHF with connectors
P/N 0010-980-000
1
CD incl. manual, set up software and AIS information
P/N 0012-972-000
The following may be needed to finish your installation but is not included:
1
VHF marine band antenna with cable and UHF or
BNC type coaxial connector.
1
GPS antenna (active antenna, built-in LNA, 20dB gain
min., 5VDC) with cable and TNC coaxial connector
2
3A Fuse with fuse holder
1
DC cable, for the DC power installation
4
Mounting screws
1
Installation materials such as mounts for the
antennas, cable ties, screws, connection blocks etc.
