TRUE RESIDENTIAL
™
MODE NAVIGATION
The following pages illustrate unique customer input operations performed at the control panel. The input
operations described are:
TEMPERATURE UNIT SELECTION MODE, VACATION MODE, AND HOLIDAY MODE.
(SEE FIGURE 10).
NOTES: (HOLIDAY MODE)
• SET-POINTS CANNOT BE CHANGED AND MANUAL DEFROST CANNOT BE INITIATED.
• THE FOLLOWING HOLDS TRUE IN ACCORDANCE WITH STAR-K REQUIREMENTS:
- Freezer defrosting functions will convert to a fixed time base sequence.
- The compartment/zone thermistors will still detect cut-in and cut-out, which is the determining factor to
start/stop the cooling process, but there will be a random sixteen (16) to twenty-one (21) second delay
before cooling begins/ends.
- The phrase “HOLIDAY MODE ACTIVE” in the LCD remains energized when the door is closed.
MODE
MODE
MODE
Te mperatureºf
Vacation Mode
Activate Holiday Mode
Te mperature ºf
Vacation Mode
Activate Holiday Mode
Te mperatureºf
Vacation Mode
Activate Holiday Mode
Te mperature Is
Celcius
press any key to
exit
Holiday Mode Active
press any key to exit
Vacation Mode
Active
press any key to exit
Te mperature Is
Fahrenheit
press any key to exit
MODE
MODE
NAVIGATION
-4°F
34°F
FIGURE 10 - MODE NAVIGATION
