GDM FREEZER / REFRIGERATOR
TEC_TM_105 | REV. D | EN 05/16/2023 Page 33 of 40
truemfg.com
Slide Door Removal
Maintenance & Servicing (cont.)
1. Position the doors as described below:
• Two-Door Appliances Slide the front door so it is centered
on the appliance. See figs. 1 and 2.
• Three-Door Appliances Center the middle door on the left
edge of the right door. See fig. 3.
2. After centering, lift the door and tilt the top of the door back
until the rollers are out of the top channel. Then, swing the
bottom of the door out of the bottom channel. See fig. 4.
Two-Door appliances skip to step 5
3. Slide the right door to the left and align the left edge with
the beginning of the TRUE Logo at the top of the door frame
(see fig. 5). Then lift the door out of the track as described in
step 2 (see fig. 4).
Fig. 1. Door channel openings (two-door appliances ONLY).
Fig. 2. Position the front door at the center of the appliance.
Fig. 4. Carefully remove the door.Fig. 3. Center the middle door on the right door’s left edge.
USER ACTION
• DO NOT use the side latch before removing the
slide door. The tension on the door cord is needed
to execute these operation instructions.
• Doors CANNOT be removed unless they are
positioned as stated in these instructions.
CENTERED DOOR
CENTERED DOOR
Two-Door Appliance
Three-Door Appliance
