GDM FREEZER / REFRIGERATOR
TEC_TM_105 | REV. D | EN 05/16/2023 Page 35 of 40
truemfg.com
Fig. 1. Door latch is in the open position (engaged with notch).
Fig. 1. Adjust the roller.
Fig. 2. Door latch is in the closed position (disengaged from notch).
Maintenance & Servicing (cont.)
Slide Door Adjustment
Only adjust the appliances after it has been installed in its final
location and correctly leveled.
Procedure
1. Completely close the slide doors and check for openings. If
there are any gaps/openings between the closed doors and
appliance, the doors will need to be adjusted.
2. With a 7/16" wrench or adjustable wrench and 1/8" Allen
wrench, loosen the roller and move it along the slotted hole.
After the adjustment has been made tighten the roller into
place. See fig. 1.
Slide Door Hold-Open Feature
The hold-open feature keeps the door in the open position.
Procedure
1. Slide the door open.
2. Latch the door in the open position from the back side of door
(notch in track). See figs. 1 and 2.
NOTICE ›
Figs. 1 and 2 show the rear view of the door
and track.
