GDM FREEZER / REFRIGERATOR
TEC_TM_105 | REV. D | EN 05/16/2023 Page 9 of 40
truemfg.com
CLEARANCES
MODEL TOP SIDES BACK
G4SM 0" (0 mm) 0" (0 mm) 1" (25.4 mm)
GDM-05/05F
12" Open
(304.8 mm)
1" (25.4 mm) 1" (25.4 mm)
GDM-07F 1" (25.4 mm) 1" (25.4 mm) 3" (76.2 mm)
GDM-10/12/10-58 1" (25.4 mm) 0" (0 mm) 1" (25.4 mm)
GDM -11SD 0" (0 mm) 0" (0 mm) 1" (25.4 mm)
GDM Freezers 3" (76.2 mm) 0" (0 mm) 3" (76.2 mm)
GDM Refrigerators 0" (0 mm) 0" (0 mm) 1" (25.4 mm)
GEM 0" (0 mm) 0" (0 mm) 1" (25.4 mm)
About Your Appliance & Installation Requirements (cont.)
Clearances
Be sure your appliance has the required surrounding clearances for
ventilation purposes. Keep all ventilation openings in the appliance
enclosure or structure housing the appliance clear of obstruction.
NOTICE!
Warranty is void if ventilation is insufficient.
